7370A

SAM™ Studio Subwoofer

Der 7370A Subwoofer passt sich intelligent an Ihre Raumakustik an, um eine kontrollierte, unverfälschte Tiefbass-Wiedergabe zu erreichen.

Active Crossovers

Bass Management System


SPL

113 dB

Frequenzgang

19 Hz - 150 Hz (-6 dB)

Abmessungen

H 625 x W 555 x D 496 mm, (Anzeige in Inch)

Sauber und präzise

Der 7370A bietet im Vergleich zu unseren kleineren SAM Subwoofern höheren SPL und eine tiefere untere Grenzfrequenz. Das Laminar Spiral Gehäusedesign garantiert dabei eine saubere, präzise Wiedergabe mit extrem geringen Verzerrungen - selbst bei hohen Wiedergabepegeln. Der 7370A wurde für anspruchsvolle Musik-, Post- und Broadcast-Profis entwickelt und wird selbst in herausfordernden Umgebungen jahrzehntelang zuverlässige Dienste leisten.

Tiefbass, der sich perfekt überträgt

Der 7370A bietet außerdem integriertes Bassmanagement, Mehrkanal-Anschlussmöglichkeiten und kann mit unserer GLM-Software konfiguriert und kalibriert werden. GLM analysiert Ihre Raumakustik und passt Frequenzgang, Pegel, Laufzeiten und Phasenlage auf intelligente Weise an - so dass Monitore und Subwoofer perfekt aufeinander abgestimmt sind. Dieser Prozess führt zu einem wirklich optimierten Hörerlebnis und liefert Mischungen, die sich hervorragend übersetzen.

Genelec

7370A SAM™ Studio Subwoofer

Farboptionen
Lieferumfang:

1 x 7370A Subwoofer
1 x Stromkabel 1,8 m
1 x RJ45 Kabel 5 m
1 x Betriebsanleitung

Genelec

7370A SAM™ Studio Subwoofer

Farboptionen

Technische Spezifikationen

SPL

113 dB

Verstärkerleistung

400 W Bass (Class D)

Frequenzgang

19 Hz - 150 Hz ("-6 dB")

Genauigkeit des Frequenzgangs

± 3 dB (19 Hz - 100 Hz)

Treiberabmessungen

305 mm Bass (Anzeige in Inch)

Abmessungen

H 625 x W 555 x D 496 mm, (Anzeige in Inch)

Gewicht

48 kg / 105.8 lb

Anschlüsse

8 x XLR Analog Input

8 x XLR Analog Output

1 x XLR AES/EBU Input

1 x XLR AES/EBU Output

2 x RJ45 Control

1 x XLR Analog Input

1 x XLR Analog Output

Schlüsseltechnologien

Active Crossovers

Bass Management System

Intelligent Signal Sensing (ISS™) Technology

Laminar Spiral Enclosure (LSE™) Technology

Optimised Amplifiers

Protection Circuitry

Smart Active Monitor (SAM™) Systems


Referenzen

Using GLM | Walkthrough

Using GLM | The foundations

Using GLM | Controlling GLM with MIDI

Using GLM | Calibration Group IDs

Using GLM | GRADE Room Acoustic Report

Using GLM | Accounts and product registration

Using GLM | The technical details


Händler finden

Geben Sie Ihre Stadt ein, um den nächst gelegenen Händler anzuzeigen.

Filters
X Filters
All
Studiomonitore
Home Audio Lautsprecher
AV Installationslautsprecher
Technischer Service
Showroom
Experience Centre
SAM Certified
Smart IP Certified
Land

Dokumentation

FAQ

The Classic 8000 Series monitors have an analogue input. The 7200 Series SAM subwoofers have AES/EBU digital outputs only. However, other 7300 Series SAM subwoofers have analogue inputs and outputs and can be used also with analogue monitors.

Which SAM™ Products You Are Going to Mix With the Classic 8000 Series?
Mixing 8000 Series and SAM™ monitors is not recommended

We do not recommend mixing Classic 8000 Series monitors with SAM™ Monitors.
If the analogue input sensitivity of 8000 Series and SAM™ Series monitors are the same, Genelec SAM™ Monitors exhibit a slightly larger latency (< 5 ms) than 8000 Series monitors. Therefore Classic 8000 Series and SAM™ Series monitors should not be mixed in a stereo pair or multichannel setup.

It is alright to mix Classic 8000 Series with SAM™ Subwoofers

However, it is okay to mix the Classic 8000 Series monitors with SAM™ Subwoofers. Any Classic 8000 Series monitors can be used with SAM™ Subwoofers, in any stereo or multichannel setup.

Setting the room response calibration controls

Genelec monitors are calibrated flat in anechoic free field conditions. When the monitor is placed in a room close to walls or other boundaries, the low frequency output of the monitor increases. To achieve a flat low frequency response an adjustment of typically -4 dB on the bass tilt control is used. Genelec also provides a bass roll-off control to compensate for any remaining excessive LF energy around the low cut-off frequency.
Genelec GLM AutoCal can implement a more precise compensation after measuring the acoustic effects produced by the monitor’s installation location.

Differences in room reverberation time and listening distance can lead to changes being required in the treble region so treble tilt is fitted to most of the models in the Genelec range.

In three-way monitors and large main systems there are additional driver controls for the bass level, mid level and treble level which enable very fine adjustment of the frequency response so that the monitors can be placed in many different listening environments, whilst still achieving a consistent and neutral sound reproduction.

The best way to set the room response controls of a Genelec monitor is by taking an acoustical measurement at the listening location, using a measurement system for those products that offer local controls (DIP switches) on the monitor or subwoofer, or by using GLM AutoCal for the SAM™ (Smart Active Monitoring) products.
